TX02-ASK

ASK Hybrid SAW Based Transmitter

TX02-ASK

433Mhz ASK Hybrid SAW Based TransmiTTER

TX02-ASK is 433Mhz (315Mhz also available) ASK Hybrid SAW based transmitter provides a complete RF transmitter solution, which can be transmitted data from any microprocessor or standard Encode IC. The compact size and low cost design keeping the components limited and ensuring the low hardware cost. The module is compatible with DIGIMORE range of ASK receiver modules.

FEATURE

  • Wireless Security Systems
  • CMOS/ TTL Input
  • Stable Operating Frequency
  • Low Current Consumption
  • Wide Operating Voltage 3 ~ 5.5VDC
  • Available for 315/ 433.92Mhz

SPECIFICATION

Supply Voltage 3 ~ 12 V
DATA Rate: 1Kbps 315Mhz  4 ~ 15 dBm
Supply Current  7 ~ 33  mA
433Mhz  4 ~ 15 dBm
Supply Current  7 ~ 33  mA
Data start out by VCC turn on 10 ~ 20 Ms
Data Rate 1K ~ 3 K Bps
Offset +/- 75 Khz
1Kbps data rate 45 ~ 55 %
