FPrfid-S50-1

Fingerprint Mifare S50 RFID Contactless Card, passive Power

FPrfid-S50-1

RFID Card built-in Capacity Fingerprint Sensor

FPrfid-S50-1 is a 13.56Mhz Mifare S50 RFID card without a thin battery, featuring a built-in capacitive fingerprint sensor. It includes an MCU with embedded recognition algorithms and a 6H hardness Cermet-like coating for durability. Ideal for access control, locks, safes, and high-security applications. Easy fingerprint management with provided software.

FEATURE

  • Fully compatible with 13.56Mhz Mifare S50 RFID
  • Passive power supplied from RFID card reader (depend on card reader)
  • Built-in capacitive fingerprint sensor with cermet-like coating
  • Register up to 5 fingerprint templates with 8 images each
  • Built-in solid state battery in RFID card for fingerprint sensor
  • Compliance with ISO/IEC 14443-1 4.3.3, ISO/IEC 10373-1 5.8
  • 300 times operation based on 6 sec.
  • Fingerprint enrollment software for administrator.

SPECIFICATION

Mifare RFID Card
Card Size 85.6 (L) x 54 (W) x 0.74 ~ 0.84 (T) mm
Chipset Philips MF1 IC S50
Card Material PVC, ABS or other as requested
Power/ LED Indicators 1 x power button / Red indicates power, Green indicates fingerprint
Power Source Solid state battery for fingerprint sensor
Warping/ Curl Test Compliance with ISO/IEC 14443-1 4.3.3., ISO/IEC 10373-1 5.8
Capacitive Fingerprint Sensor
Resolution 508 dpi
Sensing Area 8 x 8 mm or 160 x 160 pixel
Supply Voltage Passive power supplied from RFID card reader
Hardness/ Surface Up to 6H/ Cermet-like coating
FAR/ FRR False acceptance rate (FAR) 0.0001; False rejection rate (FRR)<2%
Fingerprint Number 5 finger number, 8 images for each finger
Battery Life 300 times operation based on 6 sec.
Operating Temperature -10 ~ 50o C/ <RH 20 ~ 85%
