FPrfid-S50
RFID Card built-in Capacity Fingerprint Sensor
FPrfid-S50 is a powerful 13.56Mhz Mifare S50 RFID card built-in capacitive fingerprint sensor with MCU embedded recognition algorithms. The Cermet-like coating of fingerprint sensor provides up to 6H hardness and protects sensors against scratch, impact and daily wear-and-tear. It can be widely applied in various fields such as access control systems, locks and safes, high-level security applications and other standalone authentication applications. With software of fingerprint enrollment, administrator can easily manage fingers enrollment.
FEATURE
- Fully compatible with 13.56Mhz Mifare S50 RFID
- Built-in capacitive fingerprint sensor with cermet-like coating
- Register up to 5 fingerprint templates with 8 images each
- Built-in solid state battery in RFID card for fingerprint sensor
- Compliance with ISO/IEC 14443-1 4.3.3, ISO/IEC 10373-1 5.8
- 300 times operation based on 6 sec.
- Fingerprint enrollment software for administrator.
SPECIFICATION
| Mifare RFID Card | |
| Card Size | 85.6 (L) x 54 (W) x 0.74 ~ 0.84 (T) mm |
| Chipset | Philips MF1 IC S50 |
| Card Material | PVC, ABS or other as requested |
| Power/ LED Indicators | 1 x power button / Red indicates power, Green indicates fingerprint |
| Power Source | Solid state battery for fingerprint sensor |
| Warping/ Curl Test | Compliance with ISO/IEC 14443-1 4.3.3., ISO/IEC 10373-1 5.8 |
| Capacitive Fingerprint Sensor | |
| Resolution | 508 dpi |
| Sensing Area | 8 x 8 mm or 160 x 160 pixel |
| Supply Voltage | 3.0 ~ 3.6VDC |
| Hardness/ Surface | Up to 6H/ Cermet-like coating |
| FAR/ FRR | False acceptance rate (FAR) 0.0001; False rejection rate (FRR)<2% |
| Fingerprint Number | 5 finger number, 8 images for each finger |
| Battery Life | 300 times operation based on 6 sec. |
| Operating Temperature | -10 ~ 50o C/ <RH 20 ~ 85% |
